Taski AERO 3500 micro - Page 114

GTS Technical Manual
9. April 2021 Edition: V1.00/2021 6-18
Copyright © 2020, Diversey
06.18.30 electronics - connections - 2100µicro_4000_5000_3500µicro_V2.00.fm
26 X41 Throttle (Hall sensor throttle) 3 Output (Signal)
26 X41 Throttle (Hall sensor throttle) 4 Not connected
26 X41 Throttle (Hall sensor throttle) 5 Not connected
26 X41 Throttle (Hall sensor throttle) 6 Not connected
27 X51 Control unit 1 Emergency stop IN
27 X51 Control unit 2 Coding 1 (TASKI swingo 4000)
27 X51 Control unit 3 Coding 2 (TASKI swingo 5000)
27 X51 Control unit 4 Coding 3 (TASKI swingo 2100µicro)
27 X51 Control unit 5 Coding 4 (TASKI AERO 3500µicro)
27 X51 Control unit 6 Not connected
28 X60 Charger 1 GND
28 X60 Charger 2 Plus (+) 12VDC
28 X60 Charger 3 Not connected
28 X60 Charger 4 Battery detection
28 X60 Charger 5 Battery charge detection
28 X60 Charger 6 I2C: SCL
28 X60 Charger 7 I2C: SDA
28 X60 Charger 8 Battery charge detection input reset
29 X61 Chem. (IntelliDose) 1 Plus (+) 24VDC
29 X61 Chem. (IntelliDose) 2 Plus (+) 24VDC
Pos. Plug Description [plug] Pin Description [pin]
Table 2: Electronics connections
