In the OBC operating mode the record line is defined using the form
layout functions available. These provide opportunities for individual
adjustment. The resulting heightened expectations for information
presentation are satisfied by the offer of additional form modules.
When combining one or more measurement systems, a CAN
termination must similarly be set for the last MultiFlow in the chain only.
None of the other terminations may be activated!
9.3.1.14.1.3
Setting up a RF base station (remote operation)
The MultiControl package from Sening comprises the following
components - base station, handheld controller with display, start/stop
function and dead man’s switch, and also the limit value sensor for overfill
protection.
The three basic MultiControl functions are, in addition to motor start/stop:
Remote control of the MultiFlow with pre-set volume or flow display,
discharge start/stop, etc. parameter 3.1.6.4
Overfill prevention, parameter 3.1.6.5
Dead man’s switch, parameter 3.1.6.6
These functions can be activated independently of each other and
allocated to separate base stations. Each parameter group thus has the
option of activation of any particular function and of setting the CAN Bus
node number. Usually, however, the functions are dealt with via a single
base station with the node number “0”.
RF activation of overfill prevention does not take place in menu
3.1.6.5, but under parameter 3.1.8.8, see chapter 9.3.1.8 "Valve
Control" / page 145.
The “transmission interval” parameter for the dead man and overfill
prevention settings defines the interval at which the base station must
cyclically provide a status value (“heartbeat”), failing which the MultiFlow
changes to a ‘fault’ state.
