MultiFlow  Configuration of the MultiFlow
 The return flow states the amount of product which the MultiFlow may
count in the reverse direction before an error message is output. A normal
value is eight liters.
Pulse Counter Menu
 The maximum error pulses
state the number of pulses
which are regarded as
erroneous. If this number is
exceeded, then a pulse error is
issued and the discharge
terminated.
 Define the connected pulse
sensor by entering the sensor
type.
An NPN, PNP or THS sensor
can be connected. You can
determine the correct type of
sensor from the identification-plate on the flow meter.
 Normally with a GMVT 703 or GMVZ 1003, a sensor type with a PNP
switching output is used. A THS sensor is used with the GMVT 704,
GMVT 805 and GMVZ 1004 measuring systems.
 Error pulses are not evaluated if the actual flow is below ½ of the min.
flow rate. Additionally, after consecutive 30 seconds of too low a flow
rate, the delivery will be interrupted with a corresponding warning.
 If the min. flow rate is set to 0, error pulses are evaluated in all cases,
deliveries will not be interrupted on min. flow.
9.3.3.2 Temperature Sensor
No.
Name
Seal
K
Factory
Setting
Meaning
3.3.2
Temperature sensor
3.3.2.1
Temp. Offset
Cal.
1
Preliminary
certificate
Figure for temperature offset according to
W&M certificate.
0
Offset 0°C
-
0
Device size
Setting for temperature offset.
IMPORTANT: The parameter is set during the
preliminary test and cannot be
changed.
0
Offset 100°C
-
0
Device size
Setting for temperature offset.
IMPORTANT: The parameter is set during the
preliminary test and cannot be
changed.
P u ls e In pu ts
S el ec ti on : 33 1
1 Pu ls e Ra ti ng
2 Ma x. Re tu rn V olu me
3 Ma x. Er ro r P uls es
4 S en so r Ty pe
5 Mi n. F lo w Ra te
Up Do wn ---
