MultiFlow  Configuration of the MultiFlow
No.
Name
Seal
K
Factory
Setting
Meaning
3.5.nn.7
Temp.
compensation
3.5.nn.7.1
Compensation
Cal.
1
1 (yes)
Activation of compensation:
1. No:
Compensation deactivated.
Printout carried out with VT.
2: Yes (receipt: V0&VT):
VT and V15 printout carried out using form
module 12.
(Use for products with voluntary compensation.)
3: Yes (receipt: V0):
V0 printout carried out using form module 12.
(Use for products with statutory compensation.)
3.5.nn.7.2
Comp. temperature
Cal.
1
15°C
Selection of compensation temperature
3.5.nn.7.3
Product group
Cal.
1
Determination of the compensation algorithm in
dependence of the product group:
1 Packed Goods
2 Crude Oil (API-Table 54A)
3 Refined Oil (API-Table 54B)
4 Special Product (API Table 54X)
for liquid gas & bitumen
5 Lube Oil (API-Table 54D)
6 Direct-Linear (Mixed Products)
for e.g. E5, E10 …
3.5.nn.7.4
Mean density
Cal.
1
Physical constant specified by W&M.
3.5.nn.7.5
Meter Factors
3.5.nn.7.5.1
Meter Factor 1
Cal.
1
See "Fehler! Verweisquelle konnte nicht gefunden
werden."
3.5.nn.7.5.2
Meter Factor 2
Cal.
1
See "Fehler! Verweisquelle konnte nicht gefunden
werden."
3.5.nn.7.5.3
Meter Factor 3
Cal.
1
See "Fehler! Verweisquelle konnte nicht gefunden
werden."
3.5.nn.7.5.4
Meter Factor 4
Cal.
1
See "Fehler! Verweisquelle konnte nicht gefunden
werden."
3.5.nn.7.5.5
Flow Rate 1
Cal.
1
Upper limit of validity range for Meter Factor 1
3.5.nn.7.5.6
Flow Rate 2
Cal.
1
Upper limit of validity range for Meter Factor 2
3.5.nn.7.5.7
Flow Rate 3
Cal.
1
Upper limit of validity range for Meter Factor 3
3.5.nn.7.5.8
Flow Rate 4
Cal.
1
Upper limit of validity range for Meter Factor 4
3.5.nn.7.5.9
Copying from ...
Cal.
1
Copies the calibration data (see above) from a
different product register.
3.5.n.n.7.6
Min. product temp.
Cal.
1
99
Autom. end of delivery in the event of temperature
shortfall. Applicable range -20°C to 20°C. The value
99 deactivates this function.
3.5.nn.7.7
Change factor
Required for product group "6 Direct-Linear" to
temperature volume compensation of mixed products
(E5, E10 ...)
3.5.nn.7.7.1
Min. temperature
Cal.
1
-20
Min. temperature for temperature volume
compensation -120 .. 120°C
3.5.nn.7.7.2
Max. temperature
Cal.
1
50
Max. temperature for temperature volume
compensation -120 .. 120°C
3.5.nn.7.7.3
Change factor
Cal.
1
0
Density change factor to calculate according to
"Method 1" in [1 / K]
-1000.0 1000.0 ...,
Minimum value: + /-1.0E-7
3.5.nn.8
Hose set
M
2
WP
Allowed hoses for this product, see parameter
3.1.8.7
