Press key <1> briefly twice. The letter B appears in the text window.
With function key <F1> the letter entry is set to "lowercase".
......
Press key <7> briefly 3 x. Then a small "u" appears after the letter B in
the text window. Continue the procedure until the complete product
name has been entered.
Confirm the entered name by pressing <PRINT>.
Next, the product type (key <2>) must be defined. This product is an
additive which is to be dispensed through the pump.
Select "Additive" with key <3>.
Operation then automatically returns to the start menu.
The W&M code can be selected with key <3>. In this example 20 is
entered, since an additive is involved.
(Entry only required for additive dispensing after the measuring
system).
With key <4> you define the unit. An additive is normally measured in
milliliters (ml). The unit is selected by pressing the appropriate number
or key F1 <Up> or F2 <Down>.
The selected unit is accepted with <Enter>.
The entry of liters (l) is also possible as an alternative.
With key <5> the additive dispensing parameters are called up.
Under point <3> you enter the mixing ratio.
Example: For additive dispensing of 1:2000, "2000" must be entered.
The selected mixing ratio is accepted with <Enter>.
The additive options are left with <Stop>.
The next step is to define the price preset.
Press <6> and <1> to go to the scale prices input. Enter the respective
price depending on the delivery quantity.
Press <Print>. MultiFlow has now accepted the price.
If you are specifying only one price irrespective of the delivery quantity,
define only scale price 1. Set all further scale prices and delivery
quantities to "0".
Confirm the entered price by pressing <Print>.
Take note of parameter 3.1.4.0 for differentiating between net and
gross! The additive price is only used if injection takes place after the
measuring system.
The price factor indicates the quantity factor. In our case the price
refers to 1000 ml, so 1000 is entered as the price factor.
Confirm the entered price factor by pressing<Print>.
