CRP PIN Table Window
PIN Enable Check Box
The PIN Enable check box indicates a PIN number is required to create a crosspatch.
Entry Field
The Entry field indicates the crosspatch number for the PIN.
PIN Field
The PIN field is used to enter a PIN number for the displayed crosspatch entry number.
This field can contain up to 4 digits.
Submit Button
The Submit button, located at the bottom of each configuration window, is used to upload changes to the IP-223.
To permanently save changes, do the following:
1. Click Submit.
The changes are sent to the IP-223 in temporary storage.
2. Click Save to EEPROM.
The Save to EEPROM window opens.
3. Click Save Parameters.
Changes are now permanently saved to the IP-223 console.
Prev 30 Entries Button
The Prev 30 Entries button is used to traverse the window between crosspatch PIN entries 1 and 300.
PIN Setup
