APPENDIX C
Tone Frequency Table
Tone Frequency Table
TABLE 17. Supported Radio Dispatch Tone Frequencies
Tone Number
Code Digit
European Tone Frequencies in Hz Motorola
ZVEI1
ZVEI2
KEN
PZVE I
DZVEI
PDZVEI
CCIR1
CCIR2
PCCIR
EEA
EURO
SIGNAL
NATE L
EIA
MODAT
TONE 0 0 2400 2400 815 2400 2200 2200 1981 1981 1981 1981 979.8 1633 600 637.5
TONE 1 1 1060 1060 882 1060 970 970 1124 1124 1124 1124 903.1 631 741 787.5
TONE 2 2 1160 1160 954 1160 1060 1060 1197 1197 1197 1197 832.5 697 882 937.5
TONE 3 3 1270 1270 1032 1270 1160 1160 1275 1275 1275 1275 767.4 770 1023 1087.5
TONE 4 4 1400 1400 1117 1400 1270 1270 1358 1358 1358 1358 707.4 852 1164 1237.5
TONE 5 5 1530 1530 1209 1530 1400 1400 1446 1446 1446 1446 652.0 941 1305 1387.5
TONE 6 6 1670 1670 1308 1670 1530 1530 1540 1540 1540 1540 601.0 1040 1446 1537.5
TONE 7 7 1830 1830 1415 1830 1670 1670 1640 1640 1640 1640 554.0 1209 1587 1687.5
TONE 8 8 2000 2000 1531 2000 1830 1830 1747 1747 1747 1747 510.7 1336 1728 1837.5
TONE 9 9 2200 2200 1657 2200 2000 2000 1860 1860 1860 1860 470.8 1477 1869 1987.5
GROUP
TONE
A 2800 885 1939 970
825/
885
825 2400 1050 1055 2151
B 810 810 2270 810 740 886 930 930 930 2292
RESET
TONE
C 970 740 2098 2800 2600 2600 2247 2400 2247 2010
D 885 680 2457 885 885 856 991 2110 991 991 2292
REPEAT
TONE
E 2600 970 1792 2600 2400 2400 2110 2400 2110 2110 1062.9 1805 459 487.5
F 680 2600 680 680 1055 2400 1995 1091 1995 1091
