IP-223 Web Setup Windows Standards
IP-223 Web Setup Windows Standards
Links
Across the top of each setup window are links used to access the various IP-223 configuration pages. On the left side of the
links header, the name assigned to the unit, the MAC address, and the version number of the firmware are displayed.
FIGURE 14. IP-223 Links
TABLE 12. IP-2002 Links
Link Description
Displays the “Welcome Window” on page 45.
Displays the “Basic Ethernet Setup Window” on page 47.
Displays the “General Gain Setup Window” on page 51.
Displays the “Multicast Address Setup Window” on page 57.
Displays the “Per Line Setup Window” on page 65.
