Setup Information
66
Line Select 1 Button
The Line Select 1 button is used to navigate to the Per Line Setup window for Line 1 configuration.
Line Select 2 Button
The Line Select 2 button is used to navigate to the Per Line Setup window for Line 2 configuration.
Submit Button
To permanently save changes, do the following.
1. Click Submit.
The console name appears at the top of the Welcome window.
2. Click Save to EEPROM.
The Save to EEPROM window opens.
3. Click Save Parameters.
Changes are now permanently saved to the IP-223 console.
Line Type Field
The Line Type field displays the line type assigned to the line in the “Multicast Address Setup Window” on page 57.
Line Enabled Check Box
The Line Enabled check box, if selected, indicates the line’s port is enabled to transmit and receive audio.
The COR Setup section is used to enable LAM or COR for monitoring purposes.
NOTE:
• LAM and COR can both be selected at the same time.
• LAM and COR are used to check audio signal for processing.
LAM Enabled Check Box - Local and Tone Modes
The LAM Enabled check box is used to monitor the line for the signal level configured in the LAM Level field. see “LAM
Level Field - Local, Tone, and Console Modes” on page 73.
COR Enabled Check Box - Local and Tone Modes
The COR Enabled check box, if selected, indicates the COR I/O pins (DIG6, pin 20 of the DB25 connector) are enabled. If
selected, the IP-223 monitors the COR for line activity.
COR Active High Check Box - Local and Tone Modes
The COR (Carrier Operated Relay) Active High check box, if selected, indicates the COR active signal polarity is high.
COR Setup
