IP-223 Specifications
The specifications for the IP-223 are listed in Table 1. The specifications are subject to change without notice.
CAUTION:
This device is not PoE (Power Over Ethernet) compatible.
TABLE 1. IP-223 Specifications
Operating Temperature Range 0 to 70°C for full specifications
Power Requirements +12 to +16Vdc, semi-regulated, ~700mA
Ethernet Speed 10 BaseT or 100 BaseTX
Lease Lines 2W and 4W supported
Radio Interface ±45VDC withstand rating
Relay Contact Ratings 1A at 125Vac
Non-Relay Outputs Open collector, active low, 200mA maximum, 40V collector to emitter voltage
Radio Input Level 10mVpp to 10Vpp, adjustable
Radio Output Level 10mVpp to 10Vpp for mic level or -40 to +10dBm into 600Ω load, adjustable
Radio Output Impedance 600Ω for balanced mode, 200Ω for single ended mode
Frequency Response ±1.5dB, 300 to 3000Hz
Audio Distortion 2% THD maximum
DTMF Detection Bandwidth ± 25 Hz around center of frequency
MON timer 10ms to 9999ms, adjustable
Dimensions 8 ½” (215.9mm) Wide, 9 3/4” (247.65mm) Deep, by 1 5/8” (41.275mm) High
Actual Weight 3.75lb (1.701kg)
Shipping Weight and Dimensions 5lbs (2.267kg) ~ 12”(304.8mm) x 10”(254mm) x3”(76.2mm)
