67
Per Line Setup Window—Local, Tone, and Console Mode
Always On Radio Button - Local, Tone, and Console Modes
The Always On radio button, if selected, indicates CTCSS is on at all times.
On With PTT Radio Button - Local, Tone, and Console Modes
The On With PTT radio button, if selected, indicates CTCSS is generated only when PTT is activated.
Tape Output Radio Button - Local, Tone, and Console Modes
The Tape Output radio button, if selected, indicates CTCSS is generated. If selected, no CTCSS is generated. This audio
output is used as an analog sum of RX and TX audio for the line. The output port is single-ended capacitor coupled.
TX Delay Field - Local, Tone, and Console, Modes
The TX Delay field identifies the delay, in ms, of TX audio. When TX Ethernet packets arrive, the PTT relay is closed and TX
audio is delayed for the specified time. This provides the ability to overcome timing issues involving repeater attack time or
trunking (clear to talk) delays.
The range for this field is 0 to 2000ms.
RX Delay Field - Local, Tone, and Console Modes
The RX Delay field identifies the amount of time, in ms, RX audio is recorded and stored. RX audio is constantly recorded by
the IP-223 and when a COR or LAM triggered detect occurs, the IP-223 goes back the specified time of delay to start
generating Ethernet packets. This provides the ability to prevent lost first syllables.
The range for this field is 0 to 1000ms.
Squelch Tail Delay Field - Local, Tone, and Console Modes
The Squelch Tail Delay field identifies the amount of time, in ms, the RX audio is muted after PTT occurs. This provides the
ability to overcome squelch tail ping-pong in crosspatch modes by muting the radio RX input after PTT occurs.
The range for this field is 0 to 5000ms.
MSK Tone Delay Field - Local and Tone Modes
The MSK Tone Delay field identifies the delay, in ms, of MDC-1200 or FleetSync MSK signals (also known as MSK signals).
When Ethernet MSK signaling packets arrive, the PTT relay is closed and the MSK signal is delayed for the specified time.
This provides the ability to overcome timing issues involving repeater attack times or other system delays.
The range for this field is 0 to 10000ms.
Default is 1000ms.
CTCSS Setup
Delay Setup
