37
CHAPTER 4
Setup Information
The setup information for the IP-223 is accessed by using a web browser configuration window, such as Microsoft Internet
Explorer. This chapter includes information on setting the IP Address, accessing the IP-223 web setup windows, the setup
window standards, and an explanation of the fields on each window used to configure the IP-223.
Setting the IP Address Information
Before entering the setup information for the IP-223, the IP Address and Subnet Mask must be assigned to the IP-223 by the
use of a web browser or Windows HyperTerminal if the assigned IP Address is not accessible on your network. Contact your
network administrator to obtain the network IP Address, Subnet, and Mask.
For the IP-223 to interface successfully with the LAN or WAN, the IP Addresses of the IP-223 and your PC must be on the
same subnet. IP Addresses consist of four (4) numbers separated by periods. For example, 10.2.99.101. For more information
on IP Addresses and subnets, consult your network administrator.
In order for the PC and the IP-223 unit to communicate via IP, both devices need to be in the same subnet.
NOTE: For operation on different subnets, a gateway address must be configured.
An example of IP Addresses residing in the same subnet:
PC IP Address - 10.2.99.250
IP-223 IP Address - 10.2.99.251
IP-223 Network Mask - 255.255.255.0
To display the IP Address and Network Mask assigned to the IP-223, do the following:
1. Connect power to the IP-223.
The IP Address and subnet mask are displayed on the LCD momentarily upon power up.
2. Press and hold the line button on the front panel of the IP-223, and then momentarily press the IC button, to check
the IP Address and subnet mask at any other time,.
The IP Address is displayed on the top line of the LCD, and the Network Mask is displayed on the bottom line of the
LCD.
NOTE: Compare and verify the IP Address and Network Mask obtained from your network administrator to the
addresses configured on the IP-223.
