Setup Information
82
Auto Answer Field
The Auto Answer field identifies the number of times the phone rings before the line goes offhook. This field is used to
remotely enable a IP-223 to PIB or TDI connection.
The range for this field is 0 to 999 rings.
Auto Disconnect Time Field
The Auto Disconnect Time field identifies the amount of time, in seconds, before the IP-223 automatically places the PIB or
TDI adapter onhook or disconnects if the threshold entered in the LAM Level field is not reached.
The range for this field is 0 to 9999 seconds.
TX Delay Field
The TX Delay field identifies the delay, in ms, of TX audio. When TX Ethernet packets arrive, the PTT relay is closed and TX
audio is delayed for the specified time. This provides the ability to overcome timing issues involving repeater attack time or
trunking (clear to talk) delays.
The range for this field is 0 to 2000ms.
RX Delay Field
The RX Delay field identifies the amount of time, in ms, RX audio is recorded and stored. RX audio is constantly recorded by
the IP-223 and when a COR or LAM triggered detect occurs, the IP-223 goes back the specified time of delay to start
generating Ethernet packets. This provides the ability to prevent lost first syllables using COR.
The range for this field is 0 to 1000ms.
LAM Level Field
The LAM Level field identifies the threshold, in dB, at which the radio/line unmutes and sends RX packets to the Ethernet.
The range for this field is -50 to +10dB.
LAM Time Field
The LAM Time field identifies the amount of time, in seconds, the console continues to play audio when receiving audio
above the LAM threshold specified in the LAM Level field. This entry is also used by the Ethernet to determine how long to
send audio.
The range for this field is 0 to 60 sec.
Delay Setup
LAM Setup
