Setup Information
56
To adjust a signal level, do the following:
1. Click General Gain Setup.
The General Gain Setup window appears.
2. From the Handset Mic Gain drop down menu, select the desired gain for the handset mic.
3. From the Headset Sidetone drop down menu, select the desired gain for the headset sidetone.
4. From the Receive Gain drop down menu, select the desired receive gain for the appropriate line.
5. From the Transmit Gain drop down menu, select the desired transmit gain for the appropriate line.
6. From the CTCSS Gain drop down menu, select the desired CTCSS gain for the appropriate line.
7. In the TX Voice Gain field, enter the desired gain for the appropriate, if required.
8. Click Submit.
The entries currently displayed on the window are sent to the IP-223 for storage.
9. Click Save to EEPROM.
The Save Setup Parameters window appears.
10. Click Save Parameters.
The entries are saved to permanent memory.
Submit Button
The Submit button, located at the bottom of each configuration window, is used to upload changes to the IP-223.
NOTE: Clicking Submit saves changes in temporary memory only.
To permanently save changes, do the following:
1. Click Submit.
The changes are sent to the IP-223 in temporary storage.
2. Click Save to EEPROM.
The Save to EEPROM window opens.
3. Click Save Parameters.
Changes are now permanently saved to the IP-223 console.
