Setup Information
76
Serial Port Params Drop Down Menu - Local, Tone, and Console Modes
The Serial Port Params (Parameters) drop down menu identifies the configuration of the serial port data speed and format.
Serial port parameters refer to bit rate, parity, data bits, and stop bits.
The serial port parameters in Tone or Console mode is, by default, 19200.N.8.1.
Available selections for this field are:
REFERENCE: For more information see the Radio Dispatch and Signaling Equipment downloads available on the Telex
website (www.telex.com) for this setting.
300,N,8,1, 4800,N,8,1
300,N,8,2 4800,N,8,2
300,E,7,1 4800,E,7,1
1200,N,8,1 9600,N,8,1
1200,N,8,2 9600,N,8,2
1200,E,7,1 9600,E,7,1
2400,N,8,1 19200,N,8,1
2400,N,8,2 19200.N.8.1
2400,E,7,1 19200,E,7,1
FIGURE 34. Serial Port Params Drop Down Menu - Normal Mode
