Appendix A. Specification
210
Appendix A. Specification
5.1.1 RF SOURCE
Output Frequency
Range: 2400 MHz ~ 2500 MHz
Accuracy:  46 Hz + Frequency Reference Drift
Resolution: 1 kHz
Switching Time: < 160 us,  75 kHz of the final frequency
Output Level
Range: 0 ~ -80 dBm
Accuracy: 1 dB
Resolution: 0.1 dB
GFSK Modulation
GFSK bit rate : 1 Mbps, B X T = 0.5
Modulation index : 0.32
Modulation index range : 0.28 ~ 0.35 ( Frequency deviation range : 140 kHz ~ 175
kHz)
Modulation index resolution : 0.01
GFSK Modulation
π /4 DQPSK bit rate : 2 Mbps
π /8 DQPSK bit rate : 3 Mbps
GFSK Modulation (Low Energy)
GFSK bit rate : 1 Mbps, B X T = 0.5
Modulation index : 0.5
Modulation index range : 0.45 ~ 0.55 ( Frequency deviation range : 225 kHz ~ 275
kHz)
Modulation index resolution : 0.01
5.1.2 RF ANALYZER
Input Frequency
Range: 2400 MHz ~ 2500 MHz
Accuracy: 46 Hz + Frequency Reference Drift
Resolution: 1 kHz
LO Switching time: < 160 us,  75 kHz of the final frequency
Input Level
Range: -10 ~ -80 dBm (20 dBm ~ -30 dBm with 30 dB attenuator ON)
Absolute Max: 25 dBm
Accuracy: 1 dB,
Resolution: 0.1 dB
Intermediate Frequency
IF Frequency: 70 MHz
Filter BW: 10 MHz Max,
Sampling Rate: 40 MHz
1 MHz Digital Filter ON/OFF
