3.1 Overview
33
3.1.11 Data Input and Change
1) Press soft key related to the desired input menu.
2) The cursor indicates data input position.
3) Change value with Rotary Knob or keys. Or enter data with Key Pad.
4) Push Rotary Knob or ENT to confirm the inputted value.
5) BS (Back Space) key be used, if necessary.
6) Many menus display a list of choices when selected. Select a new setting from the
list.
3.1.12 Enter and Change the Unit-of-Measure
When the unit is implied, the current unit is used. For example; if the present Reference
Level is 0dBm, and you want to change it to 10 dBm, you would enter this sequence:
1 0 ENT
When the unit is specified, the units change to whatever you specify. For example; if the
present Reference Level is 0 dBm, and you want to change it to 10 mW, you would
enter this sequence:
1 0 mW
To change the present unit-of-measure, position the cursor in front of current unit and
press the key labeled with the desired unit
Available units:
3.1.13 Interaction Between Screens
Some menus operate globally; changing the setting in any screen automatically changes
that setting in all screens where it is available. Test Mode is an example of this menu type.
Ex) Configuration: DUT: Test Mode: Transmitter MEASUREMENT: Spectrum: Test
Mode: Transmitter MEASUREMENT: FM Modul.: Test Mode: Transmitter
MEASUREMENT: Pow-Time: Test Mode: Transmitter MEASUREMENT: Pow-
Chan: Test Mode: Transmitter Link Analyzer: LINK: Test Mode: Transmitter
3.1.14 Tool Tips
Throughout the GUI, tool tips provide useful information.
To display a tool tip, press FCN and Soft keys related to a menu. The tool tip
disappears when any key is pressed.
