5.5 Flow Chart for RS-232C Commands
148
5.5 Flow Chart for RS-232C Commands
< RF Test Cases >
START
Open COM Port, BAUDRATE
EXEC:PRESET
CONF:SYS:RF:TX_POW -30.0
CONF:SYS:DUT:PATH_LOSS 12.0
CONF:SYS:RF:ATT ON
EXEC:RFTC:CONN
CONF:SYS:DUT:TEST_MODE LOOPBACK_TEST
CONF:RFTC:SS:CH 0-39-78
CONF:RFTC:SS:HOP OFF
CONF:RFTC:SS:DIRTY_TX ON
CONF:RFTC:SS:RX_LEV -70
CONF:RFTC:SS:BYTES 10000
EXEC:RFTC:SS:RUN
[ Initialization ]
[ Basic Configuration ]
[ ACL Connection ]
[ Sensitivity single slot
configuration ]
[ Read Result Data ]
1
3
4
[ Measuring RF Test Items ]
READ:RFTC:SS:BER?
2
