This section contains information for keeping the instrument in good working
order and checking its overall performance.
Performance Test
4.1 General Information
The procedures in this chapter allow the verification of the electrical performance of TC-
3000C. It contains procedures suitable for determining if TC-3000C functions, is adjusted
properly, and meets the performance characteristics as warranted. These tests do not
require access to the interior of the instrument.
The set-up drawings at the beginning of each test procedure show the test configuration
needed for each test. To perform the test procedures you need to know basic TC-3000C
operation. You should be familiar with the front panel, the various test screens, and knob
operation. The test procedures give critical instrument settings and connections, but they
don’t tell the manufacture test specification.
