Tescom TC-3000C - Frequency Reference; Front Panel; Rear Panel; Miscellaneous

212
Useful test for measuring DEVM variance in a packet.
5.1.11 FREQUENCY REFERENCE
Internal Reference Stability:  1 ppm vs. at -20 ~ 70℃, ±1 ppm/first year
External Reference: 10 MHz
5.1.12 FRONT PANEL
RF In/Out Port: N-type, 50 ohm, VSWR <1.6
Baseband In/Out ports: 4 BNC
- RX (I, Q), TX (I, Q), Demodulation, Modulation, RX and TX Bit streams, RX and TX
Clocks, Audio
5.1.13 REAR PANEL
HCI Interface for DUT: RS-232C, USB, PCMCIA
Remote Programming Interface: TCP/IP (LAN)
5.1.14 MISCELLANEOUS
Operating temperature: 5 ~ 40℃
Line Voltage: 100 to 240 VAC, 50/60 Hz
Dimension: 375(w) x 432(d) x 220(h) mm
Weight: 10 Kg
Packing Size: 445(w) x 515(d) x 310(h) mm
Packing Weight: approx.13 kg
