3.10 Configuration of the TC-3000C
79
HV1, HV2
HV3, AUX1
DM3, DH3
DM5, DH5
EV3, EV4
EV5, 2-DH1
3-DH1, 2-DH3
3-DH3, 2-DH5
3-DH5, 2-EV3
3-EV3, 2-EV5
3-EV5
Defines the type of packet to be used in the test mode
Defines the length of a payload to be used in the test
mode (in bytes). MAX is changed according to Packet
Type
3.10.3 RF Settings
Defines TX power of the Tester. Prohibited to change if
any ACL link exists
Defines the setting of the RX attenuator of the Tester;
The dynamic range of Tester’s receiver is –80 ~ -10
dBm for ‘On’, but –30 ~ +20 dBm for ‘Off’
Automatic Gain Control Setting of Tester Controls IF
power level inside Tester’s receiver.
Defines the input range of the Tester’s receive available
only in case AGC is Off
Defines whether 10MHz Reference Oscillator is internal
or external
3.10.4 Peripherals
I-RX, Q-RX,
I-TX, Q-TX,
RX bit, RX clk
TX bit, TX clk
FSK Demod,
FSK Mod,
RX Mag,
Audio, Loop Back
Defines the signal going out through the
BASEBAND OUT port 1 on the front panel. During
operation, you can see the Baseband signals by
connecting to oscilloscope.
If you want to make a connection through
Baseband, not RF, select what you want.
