Appendix B. RF Test Cases of the TC-3000C
234
parameters.
3. The tester checks whether the DUT transmits at maximum power. If not and the DUT
supports power control, then the tester will consecutively send LMP_incr_power_req
requests until the LMP_max_power response would be received from the DUT. The time
delay between two consequential LMP_incr_power_req requests depends on the
Pow.SetTime parameter (to modify the value use: Menu  Configuration  DUT 
More3/5  Pow.SetTime, default value is equal to 1 second).
4. The DUT is set to transmit on the given frequency channel.
5. The DUT transmits packet to the tester with maximum length payload containing PRBS9.
6. Tester demodulates packet and compares each payload with the expected PRBS9 data.
7. Steps 5 and 6 are repeated for required number of packets (see the Number of packets
parameter).
8. Steps 4 to 7 are repeated for each TX frequency channels of the DUT (see the
BT  channels parameter).
Test Results
Bit_err is the bit error rate measured by comparing each payload with the expected PRBS9
data. The result has only informative character and is not used to reach a verdict.
Pkt_err is the packet error rate measured by comparing each payload with the expected
PRBS9 data. The result has only informative character and is not used to reach a verdict.
BER(%) is bit error rate in percent. The result has only informative character and is not used to
reach a verdict.
PER(%) is packet error rate in percent.
To reach a verdict the test results are compared with the limit parameters:
“Upper limit the PER”
To change the parameters, use the Edit menu of the test case. If the flag “Use Default” is
selected then all of displayed values of parameters are ignored and the values according to RF
Test Specification [1] are assigned automatically.
Requirement to Initial Condition of a DUT
If the DUT can be controlled through HCI, the DUT must be connected to an appropriate HCI
port of the tester and correct value of the HCI Port parameter must be specified in DUT
configuration (Menu  Configuration  DUT  More1/5  HCIPort).
If the DUT does not have HCI then the DUT must be in the Inquiry Scan/Page Scan state
(maximum activity of the scan mode is desirable) and Test Mode must be enabled.
5.2.13 EDR In-band Spurious Emissions (TRM/CA/13/C)
Goal
Verification that the level of unwanted signals from the DPSK transmitter, within the frequency
range used by the devices, is below the required level.
