3.10 Configuration of the TC-3000C
78
Bluetooth Device Address of the DUT
Must be entered in little ending format (LSB in the
right side) in hexadecimal notation.
6 bytes Bluetooth Device Address of the DUT, from
which the Device Access Code will be derived when
the page procedure is performed; the parameter is
used only when ‘Inq. supported’ is not checked
Defines the amount of time between consecutive page
scans, i.e., the time interval from the time when the
Host Controller starts its last page scan to the time
when it begins the next page scan.
Page Scan window
Defines the amount of time for the duration of the
page scan, and T wpagescan must be less than or
equal to the T pagescan.
Defines the maximum time the local Link Manager will
wait for a baseband page response from the remote
device at a locally initiated connection attempt.
If this time expires and the remote device has not
responded to the page at baseband level, the
connection attempt will be considered as failure.
Power setting time of DUT
Defines the interval of time Tester must wait until the
DUT will reach the new power step.
Defines whether LMP connection should be created
before activating DUT’s test mode
Defines the test mode to be used in activating DUT’s
test mode; NULL pkt means simple connection
1111 1111
1010 1010
1111 0000
PRBS9
PRBS : Pseudo Random Binary Sequence
Defines the bit pattern of a payload to be used in the
test mode
Enable/Disable of Whitening
Defines whether to scramble the packets with the
whitening sequence or not in the loopback test mode
Defines whether to use 79 hopping sequence or not in
the test mode; for ‘Off’, select the TX and RX
channels respectively
