5.5 Flow Chart for RS-232C Commands
149
Set parametes of RF test cases complying with Bluetooth specification.
. Set “TX Power”, “RX ATT”, and “Path Loss” depending on user environments.
Set user specific parameter.
Start test.
* In case of OUTPUT POWER TEST 2 ~3 procedure.
1
2
3
CONF:SYS:DUT:TEST_MODE TRANSMITTER_TEST
CONF:RFTC:OP:CH 0-39-78
CONF:RFTC:OP:PACK_TYPE LONGEST
CONF:RFTC:OP:PACK_NUM 1
CONF:RFTC:OP:HOP ON
[ Output power configuration ]
EXEC:RFTC:OP:RUN
READ:RFTC:OP:P_AVG?
READ:RFTC:OP:P_MIN?
READ:RFTC:OP:P_MAX?
[ Measuring RF Test Items ]
[ Read Result Data ]
Yes
No
Retest?
EXEC:RESET
Close COM Port
END
4
