Tescom TC-3000C - Page 150

5.5 Flow Chart for RS-232C Commands
150
< Audio Test >
START
Open Port COM, BAUDRATE
EXEC:PRESET
CONF:SYS:RF:TX_POW -30
CONF:SYS:DUT:PASS_LOSS 12.0
CONF:SYS:RF:ATT ON
EXEC:AUDIO:CONN
( EXEC:AUDIO:TALK )
EXEC:AUDIO:TEST:RUN
EXEC:AUDIO:TONE_INIT
EXEC:AUDIO:TONE_START
CONF:SYS:DUT:TEST_MODE NULL_PKT_TEST
CONF:AUDIO:PROFILE_TYPE NONE
CONF:AUDIO:TONE_FREQ 1000
CONF:AUDIO:TONE_LEV -10
CONF:AUDIO:TEST:AUDIO_IN 1000
CONF:AUDIO:NUM_AVG 1
[ ACL & SCO Connection ]
[ Initialization ]
[ Basic Configuration ]
[ Measuring AUDIO Test Items ]
[ Audio Test Configuration ]
[ Tone Generation ]
