Appendix C. The list of Save/Recall parameters
253
Location in GUI
Parameters
Initial Values
Upper limit of the PER in %
1.000
EDR In-band Spurious
Emissions
Use Default
0
# BT channels
3-39-75
Packet Type
2-longest
Test Mode
Transmitter
Number of sweeps
10
Up. lim. of the pow. dif. for chan. abs in dB
-26.00
Up. lim. of the power in a channel M-N=2 in
dBm
-20.00
Up. lim. of the power in a channel M-N>=3 in
dBm
-40.00
Max. number of excepted channels
3
Up. lim of the power in excepted channels in
dBm
-20.00
EDR Sensitivity
Use default
0
# BT channels
0-39-78
Hopping Mode
OFF
Dirty TX Mode
ON
Packet Type
2-longest
RX power in dBm,
-70.00
Number of samples for 1
st
threshold in bytes
200000
Upper limit of the BER for 1
st
threshold in %
0.0070
Number of samples for 2
nd
threshold in bytes
2000000
Upper limit of the BER for 2
nd
threshold in %
0.0100
EDR BER Floor
Performance
Use Default
0
# BT channels
0-39-78
Hopping Mode
OFF
Dirty TX Mode
OFF
Packet Type
2-longest
RX power in dBm
-60.00
Number of samples for 1
st
threshold in bytes
1000000
Upper limit of the BER for 1
st
threshold in %
0.0007
Number of samples for 2
nd
threshold in bytes
20000000
Upper limit of the BER for 2
nd
threshold in %
0.001
EDR Maximum Input
Level
Use Default
0
# BT channels
0-39-78
Hopping Mode
OFF
Packet Type
2-longest
RX power in dBm
-20.00
Number of samples in bytes
200000
