HYDROSTATIC POWER TRAIN
4181383 First Edition 5-31
5
1. Park the mower safely. (See “Park Mower Safely” on
page 1-5.)
2. Remove traction pump. (See “Traction Pump” on
page 5-27.)
3. Disassemble traction pump as shown in Figure 5-30
on page 5-30.
4. Place parts in assembly order on a clean work area
as they are removed.
NOTICE
Inspection Notes
• Keeping parts in assembly order, clean and air dry
each item for inspection.
• Inspect for worn or defective parts.
• Look for metal chips or slivers during cleaning (an
indication of damage to pump or other hydraulic
component).
• Inspect all parts for cracks, nicks, burrs, and
excessive wear. Inspect for scoring, galling, and
scratches on surfaces. Replace parts as necessary.
Assembly Notes
• Assemble the pump by reversing the order of
disassembly.
• Install new O-rings and seals. Use clean grease to
keep seals in position.
It is important that all pump parts are absolutely
clean, as contamination can result in serious
damage and/or improper operation.
Never use shop towels or rags to dry parts after
cleaning, as lint may clog passages. Dry parts
using compressed air.
Required Materials
Overhaul Seal and Gasket Kit
To Next Page
