Textron Jacobsen AR-5 Technical/Repair Manual

SPECIFICATIONS AND GENERAL INFORMATION
4181383 First Edition 2-7
2
Steering
Cutting Units
Accessories and Miscellaneous
Test Specifications
Steering System Leakage Test—
Cylinder Leakage
pt (L) Zero—Nominal Amount
Repair Specifications
Steering Wheel Nut Torque lb-ft (N·m) 25—30 (34—41)
Steering Cylinder Ball Joint-to-
Steering Arm Torque
lb-ft (N·m) 80—110 (108—149)
Tie Rod Ball Joint-to-Steering Arm
Torque
lb-ft (N·m) 30—35 (41—47)
Rear Axle Alignment Toe-In
Measurement
in. (mm) 0.0625 in (1.6)
Rear Axle Spindle Arm-to-Axle
Stop Measurement
in. (mm) 0.50 (13)
Rear Axle Steering Arm-to-Motor
Mount Bolts
lb-ft (N·m) 90—100 (122—136)
Steering Valve Port Cover-to-Port
Manifold Nuts
lb-ft (N·m) 20—24 (27—33)
Steering Valve Rotor-to-Stator
Clearance
in. (mm) 0.003 (0.08)
Repair Specifications—AR-522
Cutter Blade Retaining Screw
Torque
lb-ft (N·m) 75-90 (101-120)
Deck Motor End Cap Screws
lb-ft (N·m) 30 (40)
Fuel Tank
Capacity gal (L) 17 (65)
OPS
1/2-13 Mounting Hardware Torque lb-ft (N·m) 80 (108)
Front Tires All Models
Size 26.5 x 14.00-12
Type Ultra Trac, 6 Ply
Air Pressure
psi (kPa) 16 (111)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
