Textron Jacobsen AR-5 Technical/Repair Manual

2-8 4181383 First Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Rear Tire AR-5 Model 68080
Size Early
Models
20 x 12.00-8
Size
Late
Models
22.5 x 10.00-8
Type Turf Trac, 4-Ply
Air Pressure
psi (kPa) 12 (83)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
Rear Tire AR-522 Model 68082 and
68098
Size 22.5 x 10.00-8
Type Turf Trac, 4-Ply
Air Pressure
psi (kPa) 12 (83)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
Steering Turn Radius
Radius in. 37 (Left/Right)
Mower Speed
Transport mph (kph) 12 (19)
Mowing
mph (kph 7 (11)
Reverse
mph (kph) 5 (8)
Parking Brake Adjustments
Parking Brake Cable Nut Torque lb-ft (N·m) 20 (27)
Park Brake Adjustments
Brake Pedal Free Travel in. (mm) 1.5 (38)
