Textron Jacobsen AR-5 Technical/Repair Manual

9-2 4181383 First Edition
ACCESSORIES AND MISCELLANEOUS REPAIR
9
Specifications
OPS Mounting Hardware
1/2-13 Mounting Hardware Torque lb-ft (N·m) 80 (108)
Fuel Tank
Capacity gal (L) 17 (64)
Front Tires
Size 26.5 x 14.00-12
Type Ultra Trac, 6-Ply
Air Pressure
psi (kPa) 16 (110)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
Rear Tire AR-5 Model 68080
Size Early
Models
20 x 12.00-8
Size
Late Models 22.5 x 10.00-8
Type Turf Trac, 4-Ply
Air Pressure
psi (kPa) 12 (83)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
Rear Tire AR-522 Model 68082 and
68098
Size 22.5 x 10.00-8
Type Turf Trac, 4-Ply
Air Pressure
psi (kPa) 12 (83)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
Mower Speed
Transport mph (km/h) 12 (19)
Mowing
mph (km/h) 7 (11)
Reverse
mph (km/h) 5 (8)
Park Brake Adjustments
Park Brake Cable Nut Torque lb-ft (N·m) 20 (27)
Brake Pedal Free Travel
in. (mm) 1.5 (38)
