Textron Jacobsen AR-5 Technical/Repair Manual

ACCESSORIES AND MISCELLANEOUS REPAIR
4181383 First Edition 9-3
9
Component Location
See Figure 9-2.
Figure 9-1
1 Hood 5 Brake Control Pedal 9 Wheel Weight (2)
2 OPS 6 Work Light Kit 10 Fuel Tank
3 Seat and Mount Plate 7 Brake Assembly (2) 11 Rear Wheel (2)
4 Traction Pedal 8 Front Wheel (2)
TN1443
1
11
10
9
8
6
5
4
3
2
7
