THOMSON Amethyst III User Manual

Chapter 3 ’Web Browser Interface’ — Interface Description
162 Amethyst III DTV Smart Switch
User Manual
 : there is at least one critical alarm on this item.
The status of a switch is defined as follows:
 Critical , Major or Minor if the on-air input’s status is Critical , Major or
Minor , respectively.
 Or else, Warning if:
 The off-air input’s status is OK or Warning
and
 The on-air input’s status is Warning
or
 The delay compensation feature is configured but unlocked.
 Or else, OK .
For each pair of inputs linked to a switch, a blue background indicates
whic
h input is active. You can click an input that is not active to perform
a switch operation.
By selecting a switch, you can obtain:
 A graphical representation of the complete switch with
indication of:
 The active input (the one linked to the switch) and indication of
the status of the two inputs
 The status of the switch
 The status of all outputs
Click the inactive input to perform a manual switch operation.
Figure 3-93. Switch graphical representation
