THOMSON Amethyst III User Manual

Chapter 1 ’Overview’ — Chassis Description
28 Amethyst III DTV Smart Switch
User Manual
- When editing a string, allows selecting a letter and special
char of the alphabet.
- When editing a number, allows selecting a cipher.
 Select previous/following item in a popup box.
 Left/right arrow keys
 Anywhere in the main menu, left key drives to first item, right
key drives to last item,.
 Move highlighting cursor left and right in a list of items or in a
multiple char string.
 Select previous/following item in a popup box.
 OK key
 When pressed once on a main menu item, expands the menu;
when pressed again, collapses the menu.
 When pressed on a modifiable field (and selection mode is
active), edits this field.
 When pressed on an edited field, leaves the last value entered
and comes back to selection mode.
 Selects the highlighted item of a popup box.
 C key
It lets you switch to the edition mode.
 0-9 keys
When in edition mode, they allow entering the corresponding cipher
(
easier then up/down keys).
 Shift/menu
When editing a string value, it allows selecting upper/lower case.
F1-F6: Function Buttons
The Function buttons ( F1 , F2 , F3 , F4 , F5 or F6 ) provide you with the
following information:
 F1 : information on the inputs and outputs
 F2 : list of active alarms
 F3 : list of closed alarms
 F4 : IP settings
 F5 : general settings
 F6 : information on the product
The upper line of the LCD screen provides advice on the keys to use.
