Chapter 3 ’Web Browser Interface’ — GUI Overview
66 Amethyst III DTV Smart Switch
User Manual
Displayed configuration, Configuration in edition, Default configuration).
They are described in
Table 3-4 and Table 3-5 .
Table 3-4. Toolbar buttons (first line)
Click To
Open
Open a configuration from a file stored on a PC or
on a network drive.
New Create a new configuration manually.
Table 3-5. Toolbar buttons (second line)
Click To
Rename
Rename the configuration.
Remove Remove the configuration from the list of
configurations. It is not possible to remove the
active configuration.
Send Send the configuration to the equipment’s
memory.
Apply Make the selected configuration active on the
equipment. This button is not available if
automation is running.
Save Save the configuration to a file (to be stored on a PC
or on a network drive).
Copy Duplicate the configuration.
Check Check the configuration’s coherence.
Edit/Unedit Switch between the Edition mode and the
Read-only mode.
When clicking Unedit, all modifications in the
co
nfiguration that is currently modified are lost.
