OPUS Projektor Manual
CAN
Step1: Press on button Create a new Variable
By pressing on this button, the dialog Add New Variable appears.
User can configure following properties:
Properties
values / Range
Default values
Name (2)
max 255 characters
blank
Index (3)
0x3000-0x5FFF
blank
Sub-Index (4)
0x0-0xFE
blank
Data type (5)
BOOLEAN
INTEGER2
INTEGER8/UNSIGNED8
INTEGER16/UNSIGNED16
INTEGER32/UNSIGNED32
+ User defined Data type (if
created)
INTEGER16
