OPUS Projektor Manual
CAN
Properties
values / Range
Default values
Owner (6)
List of defined Owners
+ PClient
PClient or last used Owner
Group (7)
User defined group
+ Common
Common
Step 2: By pressing Add the new variable will be created with selected configuration
assuming that no issue is existing
Step 3: By pressing Close, the dialog Add a new Variable will be closed.
Alternative Step 2: By pressing Reset, all default values will be displayed.
Step 4: Once closed, other properties/ events can be updated using the variable manager
properties / events views.
The last created variable will be displayed. User can select an other variable by selection
Owner/Group/Variable
Following properties / Events can be configured
Properties
values / Range
Default values
Name
max. 255 characters
Index
0x3000 - 0x5fff
as created
Sub Index
0x0-0xFE
as created
Owner
CANopen owner e.g.
CANopenECU
as created
Description
blank max 255 Characters
blank
Data type
BOOLEAN
INTEGER2
INTEGER8/UNSIGNED8
INTEGER16/UNSIGNED16
INTEGER32/UNSIGNED32
+ User defined Data type (if
created)
INTEGER16
Maximum Length (in bits)
length in bits for
INTEGER/UNSIGNED
variables
length in bytes for STRING
variables
16
Minimum Value
maximum value for selected
data type
32767
Maximum Value
minimum value for selected
data type
-32768
Default Value
minimum value - maximum
value for selected data type
0
Initialize Value as Invalid
False|True
True
Remanent
False|True
False
Force writing
False|True
False
Protocol Specific
