OPUS Projektor Manual
CAN
In the second step of the dialog the CAN messages and variables for import can be selected.
To select a CAN message for import, activate the check box in the Select column in the upper
table of the dialog. With Select/deselect all CAN Messages, all messages can be selected or
deselected at once.
If a CAN message cannot be exported into a dbc file, the CAN message will be displayed
with a red error icon and cannot be selected.
The restrictions for an export are:
·
No String variables must be in a mapping. Strings are not supported by Vector
·
No Delimiter-based mappings can be exported. Delimiter-based mappings are not
supported by Vector
·
Multiplexer-Messages are only available for CANFreestyle and J1939 protocols, but not for
CANopen
