OPUS Projektor Manual
Object Reference
The Transparent property can be used to make the background of an object invisible. If the
property is disabled, the Background Color will be drawn as the background of the object. If
the property is enabled, no background color will be drawn.
Note: If a Background Image is assigned, it will be shown also if the transparent property is
enabled. This property only affects the background color.
Known Issue: Currently this property has no effect on Gauge objects if the property Draw
Boundary Bar is activated.
Default value: disabled
Possible values: enabled or disabled
Corner Radius (Theme dependent)
The corner radius property can be used to give Numeric Fields and String Fields a
rounded corner. With a value of 0 the objects will be rectangular. With a value of 1000 the
maximum roundness is set.
Default value: 50
Possible values: 0 - 1000
Please note that even though the objects don't have a rectangular shape anymore, the
objects themselves are still rectangular, and so are the borders for the objects.
Visibility
The visibility of an object can be configured with the visibility properties. Objects can be
made visible or invisible during runtime.
For more information about visibility see here .
Visibility
Enable or disable visibility for the selected object.
Default value: Disabled
Possible values: Enabled or disabled
Visibility Bit
With this property it can be defined to which bit of which visibility variable this object listens
or, alternatively, which variable should be used as a visibility switch.
For more information see here .
Default value: Value not set
Possible values: A configured visibility bit of a visibility variable or a variable name.
Input Configuration
Set As Input
Setting the Set As Input attribute to enabled makes an object editable by the user. How the
object reacts to inputs can then be configured in the other input properties below.
This property is only available for objects that can reference a variable. It is not available for
Page, Frame, Container, Virtual Keyboard, Softkey Frame, Softkey.
Default value:
·
Enabled for button objects
·
Disabled for all other objects
Possible values: Enabled or disabled
Connect To Encoder
