OPUS Projektor Manual
Object Reference
Note that the camera preview image in the tool changes with the different mirror settings.
Video Type
Here the type of the video can be chosen between analog video input or digital H.264 stream
over Ethernet:
· Analog Video Input
One of the device's analog video inputs shall be used (select which with Video Camera
property below)
· Ethernet Stream
Show a video stream received via Ethernet (see below for requirements and limitations)
Stream Type
Here the type of the Ethernet camera stream can be chosen:
· H.264 via UDP/RTP
· MJPEG via UDP/RTP
· H.264 via RTSP
UDP Port
If the Video Type was set to Ethernet stream and a Stream Type with UDP protocol was
selected, the UDP port used by the camera can be configured here.
RTSP URL
If the Video Type was set to Ethernet stream and a Stream Type with RTSP protocol was
selected, the RTSP URL can be written here.
The typical URL for Axis cameras is: rtsp://user:password@<IP>/axis-media/media.amp (e.g.
rtsp://root:root@192.168.135.90/axis-media/media.amp)
Anonymous viewing can be enabled in the camera settings. Then user:pass@ can be
omitted.
Please check the camera documentation for correct url.
Video Rotation
The camera image can be displayed rotated in 90° steps. This is useful if the camera is e.g.
mounted sideways. Please note that an automatic rotation is added when running the device
in portrait orientation.
Note the camera preview image changes with different rotation settings.
Video Camera
This property only has an effect if Video Type is set to Analog Video Input. Select one of
the 3 video inputs of the device.
Video Alignment
This property only has an effect if Video Type is set to Analog Video Input. Generally the
device tries to fill the frame or page completely with the video image. Since we maintain the
aspect ratio of 4:3 with analog cameras, it is not always possible to fill the whole object
