OPUS Projektor Manual
Device Software Update
(4) Edit device settings enables settings mask. If it is checked all parameters can
now be edited (5).
(6) Back button to go back to Start Page.
(7) Starts CAN Transfer with current settings.
Device CAN Parameter
1. Common Settings
o
CAN Port
§
Choose the CAN Port for using project updates. Either CAN 1 or CAN 2
can be used.
o
CAN Baud Rate
§
Baud Rate in [kbit/s]. HostUpdater will use this Baud Rate for project
updates.
§
Allowed Baud Rates are (20, 50 ,83.333, 100 111.11,,125, 250 ,500
,1000)
1. Expert Settings (same as PC Expert Settings )
The CAN Settings (PC and device) are saved when the project transfer has
successfully finished.
Next time you open the Updater for the same project, the last used CAN Settings
will set again.
The CAN Settings are saved in HostSettings.ini file.
How to configure CAN Parameters
When the Updater is started for a project the first time the default values will be set
for the CAN Parameters:
Default CAN Parameters:
[250 kbit/s] Project dependent
CAN Port settings
1. PC
Port of PEAK CAN dongle (Port 1/2).
2. Device
As default the CAN Port 2 is used for CAN updates on the device. But it is also
possible to use CAN Port 1. Simply set the CAN Port combo box in Device
CAN Settings appropriate.
