OPUS Projektor Manual
Tools
If the IP address of your network interface can't be changed, consider using a second
network card / USB-Ethernet interface.
The Camera Port field needs to contain the UDP communication port number on which the
camera listens. This is not the port for the actual video stream but the one for the ISO
17215 communication. Typical values are 17215 (ISO 17215), 30490 (SOME/IP-SD) or
30391 (SOME/IP).
The Local Listen Port field contains the UDP port to which the camera will send its
answers (the port on which the PC tool will listen). Typically this is Camera Port + 1.
Refer to the manufacturer documentation of the camera to get the matching addresses and
port numbers.
When hitting the Scan button, a service discovery broadcast message is sent on the
selected network. If one or more camera answer the request, they will be listed in the
Detected Cameras list.
Camera settings and configuration
When a camera is detected, it will be listed in the Detected Cameras list. Select one of the
detected IP addresses to select the camera.
The data set of the camera will automatically be requested and the information is
presented in the Device Information tab.
Device Information
The Device Identification typically shows the name and/or type of camera along with
manufacturer and hardware software revisions. The content of this field is manufacturer
specific.
The Standard Version field contains the supported ISO 17215 standard version.
The Usable Resolution Fields represent the horizontal and vertical resolution of the
camera's sensor.
The Regions of Interest field contains the number of available regions of interest that
can be configured (see below).
