display has a resolution of 800x480, it makes no sense to choose an output resolution of
1280x960).
WARNING: A certain combination of sensor geometry and output resolution may not be
supported by the camera. This is a manufacturer specific limit and can not be checked.
Please check camera documentation and error output!
In the Video Compression drop down box the type of video compression can be
selected. Select the type that is supported by the display.
The Max. Bitrate field defines the maximum bit rate used by the camera. The lower the
value, the higher the compression and the lower the used bandwidth will be:
·
Low Bitrate: High compression, worse picture quality, better display performance
·
High Bitrate: Low compression, better picture quality, worse display performance
Select a bitrate limit that gives the best compromise in picture quality and performance.
To save the settings for the selected ROI, hit the Apply the above settings of the
selected ROI to Camera button. If the check box Subscribe to this ROI is enabled, the
camera will directly use this ROI for video streaming. If the checkmark is not enabled, the
ROI settings will be saved but the camera will still stream with the settings of the
previously selected ROI (only if another ROI than the currently selected was active).
To make the settings of sensor geometry and output resolution more intuitive, a ROI
Configuration Wizard is available. Hit the ROI Configuration Wizard button to open it.
