“Examine stapler in the Saddle Stitch Unit” 349
11
Check the following 2 items before test stapling.
y Check if the finisher is securely installed on the equipment.
y Check if any of LD or LT-R paper is set in the drawer.
12
Close the front cover of the finisher.
Test stapling is automatically performed.
Test stapling will not be performed if the conditions mentioned in step 11 are not met. Be
sure to check the items mentioned in step 11 and open the front cover of the finisher and
then close it again before performing test stapling. Test stapling is necessary to prevent
void stapling.
8
Install the staple cartridge.
When installing a staple cartridge, push
it downward until it is fixed with a click
sound.
9
Pull the handle of the stapler of
the Saddle Stitch Unit toward
you to unlock it. Then return
the stapler to its original posi-
tion.
10
Insert the Saddle Stitch Unit
into the finisher carefully.
2
1
