1 BEFORE USING EQUIPMENT
36 Description of Each Component
Adjustment of the angle of the control panel
When adjusting the angle of the control panel
The angle of the control panel is adjustable at any angle between 7 and 45 degrees from the
horizontal position.
When changing the angle of the control panel, be careful not to catch your hands in the gap
between the equipment and the control panel. This could injure you.
When fixing the angle of the control panel
The angle of the control panel can be fixed by using the stopper on the backside of the control
panel (at 7 degrees from the horizontal position). The stopper is located on A when the equip-
ment is set up. Move it from the position A to B before fixing it.
A: The position where the angle is adjustable.
B: The position where the angle is fixed.
A
B
To Next Page
