EVM Reports and Printing
General EVM Setup
EVM Series User Manual
General EVM Setup
The EVM’s general settings are used to setup the instrument with basic parameters. Refer to the EVM
parameters table below for details.
1. Click on the General tab from the EVM’s Instrument Communications panel (see ❶). To change
the general settings, follow one (or all) of the selection options below.
Click on the arrow and select an option.
Click on the arrows and select a numeric value or type in a value.
2. To set the general features, click on or save (see ❷) and Send Configuration (see
❸). For more details see “Saving and sending configurations”.
Figure 6-8: General EVM setups
EVM General Parameters Table
*Note: Refer to Glossary for more detailed information
With the language setting, there are six options including: English, Spanish,
German, French, Italian, and Portuguese.
The backlight is used to illuminate the screen from a dark gray to a light gray color.
With the key click setting, you can turn the sound to “on” and each time you press a
key on the keypad you will hear a soft click sound. This can be disabled by choosing
the “off” setting.
The temperature unit is selectable either in Celsius or Fahrenheit via a drop-down
box.
The PID correction factor is automatically set to 1.0. For best results, it is
recommended to add a correction factor to the relevant VOC you intend to measure.
Note: Appendix C provides a listing of PID correction factors.
