Setting up Parameters via the Keypad
Unlock run and/or setup
EVM Series User Manual
Unlock run and/or setup
When in secure run mode or secure setup mode, a quick press of the lock/unlock soft key and entering
in the password will unlock the instrument. (See steps 5 and 6 above to for more information on entering
in the password.)
NOTE: If the entered password to unlock the instrument was forgotten, a default TSI password can
be used in lieu of the entered password, “9157”.
Auto-run
The EVM has four programmable auto-run settings including a timed-run, a date, a day of week (DOW),
and a disabled mode.
The EVM is shipped with the auto-run set to the disabled mode. Each mode has more than one setting
and is denoted by the “+” (plus) or “–”(minus) soft key symbols. When an alarm is activated (or
programmed), a “+” (plus) sign appears. The default alarm mode is set to an off mode and is denoted
via a minus symbol (i.e., “–”).
Auto-run and timed-run mode
With timed-run, you manually start the run (via the run key), and it will automatically stop based on the
programmed duration.
Setting auto-run with timed-run mode
1. From the Start screen, select and open the Setup screen.
2. Select Auto-Run by pressing ▲/▼ Arrows and press Enter
.
3. In the Auto-Run screen, press enter to select Timed-Run. If it is not displayed, press ▲/▼
Arrows repeatedly until selected.
4. Next, press the -ONE soft key or select View/Set Parameters.
Auto-Run and Timed Run setting
Select Timed-run by pressing Enter and then
press Up/Down arrows to move through the menu.
Timed Run soft key
Select first soft key to access the Timed run screen
Figure 3-22: Selecting auto-run with timed-run mode
