Setting up Parameters via the Keypad
PID Sensor Setup
EVM Series User Manual
4. Optional: To view the Estimated Run Time, select this field (by pressing ▲/▼ Arrows) and press
Enter
. The estimated run time screen will appear.
NOTE: To extend the logging time, turn a logged measurement(s) to “Off” and/or change the
log interval. Then, re-check the estimated run time.
Estimated run time
**NOTE: To increase the total duration, log
only one or two measurements
and/or change the log interval.
Figure 3-6: Estimated run time for logging screen
5. Press On/Off/Esc
repeatedly to return to the Start screen.
PID Sensor Setup
For best PID testing results, it is recommended to add a correction factor to the relevant VOC you intend
to measure. Refer to the PID correction factors table in Appendix C for more details.
Additionally, the PID setup screen is used to set the ppb zero cal to either enabled or disabled
(if applicable).
