Setting up Parameters via the Keypad
Checking Battery Power
EVM Series User Manual
Check battery power
1. From the start screen, highlight Setup (by pressing ▲/▼ Arrows) and press Enter
.
NOTE: If viewing a measurement screen, press the right/left arrow until the start screen
appears.
Start screen
Highlighting indicates “Setup” menu is selected
Measurement screens
Press right or left arrow to view
Figure 3-2: Start screen
2. Repeatedly press ▲/▼ Arrows until Battery is selected.
3. In the Battery setup screen, it will display the remaining capacity on the battery pack.
4. To return to the Start screen, press On/Off/Esc
twice.
Battery indicator has all bars representing fully charged
battery
Indicates remaining battery capacity
Figure 3-3: Battery screen
To Next Page
