Setting up Parameters via the Keypad

Auto-run

EVM Series User Manual

6. When programmed, press Enter

. Press key repeatedly to return to the main screen.

Days

Optional Programming is set from Sunday through

Saturday. Example displays Monday through Friday

S (hours:mins:secs)

Start time is programmed at 8 am

D (hours:mins:secs)

Duration is programmed for 4 hours

Figure 3-26: Setting auto-run DOW mode

 NOTE: To initiate the programmed run, either power down the instrument or leave on.
