TSI Quest EVM-7 User Manual

Instrument Information
Unit Information Screen
EVM Series User Manual
16
4. Or press the Look-up key. Then press the ▲/▼ Arrow to select and press Enter to open the
screen. (Repeat this step to view the other sensor.)
Look-up key
Impactor and profile displayed.
Pop-up box
Appears when you press the
Look-up key.
Sensors
Select and then press Enter to
view the sensor’s parameter
Figure 2-5: Selecting Unit Info. Sensors
5. Unit Info screens are displayed below.
 Screen “A” displays the particulates (PM), temperature (temp), and humidity as “Installed” or
“Enabled” sensors.
 Screen “B” displays CO
2
, CO (or installed toxic sensor), and PID with the associated serial
numbers. Air Velocity is listed as “Not Found” which indicates that the sensor was not
installed.
A
B
Figure 2-6: Viewing installed sensors
EVM-7
Sensors 1 - 3
Sensors 4 - 7
